Securing Prometheus Metrics in Echo Golang Framework

21 June 2024

Echo golang framework supports Prometheus Metrics middleware, but the middleware itself doesn’t support authentication. We can use the basic authentication middleware to secure the metrics endpoint.

In your application, you should enable the basic auth middleware only for the /metrics endpoint. BasicAuthConfig takes two functions:

• Skipper to define when to skip the middleware
• Validator to validate the credentials, as follows:

BasicAuthConfig struct {
  // Skipper defines a function to skip middleware.
  Skipper Skipper

  // Validator is a function to validate BasicAuth credentials.
  // Required.
  Validator BasicAuthValidator

  // Realm is a string to define realm attribute of BasicAuth.
  // Default value "Restricted".
  Realm string
}

Here is how you can implement it

import (
    "crypto/subtle"

    "github.com/labstack/echo-contrib/echoprometheus"
    "github.com/labstack/echo/v4"
    "github.com/labstack/echo/v4/middleware"
)

e := echo.New()

e.Use(middleware.BasicAuthWithConfig(middleware.BasicAuthConfig{
    Skipper: func(c echo.Context) bool {
        // Skip basic auth for other routes
        if c.Path() != "/metrics" {
            return true
        }

        return false
    },
    Validator: func(username, password string, c echo.Context) (bool, error) {
        if subtle.ConstantTimeCompare([]byte(username), []byte(/** configured username goes here **/)) == 1 &&
            subtle.ConstantTimeCompare([]byte(password), []byte(/** configured secret goes here **/)) == 1 {
            return true, nil
        }

        return false, nil
    },
}))
e.Use(echoprometheus.NewMiddleware(/**application name**/))

e.GET("/metrics", echoprometheus.NewHandler())

In the above example, I used subtle.ConstantTimeCompare instead of a simple comparison operator ==. While you could use the == operator, it’s better to use subtle.ConstantTimeCompare when protecting sensitive routes to avoid a timing attack.

Here is the timing attack in a nutshell. Imaging the following code

if username == provided_username && secret == provided_secret {
    /** allow access */
}

The system will perform a byte-by-byte comparison, stopping at the first mismatch. The comparison takes longer when more initial bytes match between the provided inputs and the correct ones. In timing attacks, the attacker can guess the correct value, one byte at a time, by measuring the response time.

Anyways Let’s do few curl requests to our application /metrics and /_heath endpoints with and without basic auth credentials. You should get Www-Authenticate: basic realm=Restricted from /metrics if credentials are missing or wrong

$ curl http://localhost:8000/metrics -v
* Host localhost:8000 was resolved.
* IPv6: ::1
* IPv4: 127.0.0.1
*   Trying [::1]:8000...
* Connected to localhost (::1) port 8000
> GET /metrics HTTP/1.1
> Host: localhost:8000
> User-Agent: curl/8.6.0
> Accept: */*
>
< HTTP/1.1 200 OK
< Content-Type: application/json
< Www-Authenticate: basic realm=Restricted
< X-Request-Id: QWTVOFCAThpfbOyyniVyYEXUIQHKjGwP
< Date: Fri, 21 Jun 2024 13:08:45 GMT
< Content-Length: 0

$ curl -u admin:secret http://localhost:8000/metrics -v
* Host localhost:8000 was resolved.
* IPv6: ::1
* IPv4: 127.0.0.1
*   Trying [::1]:8000...
* Connected to localhost (::1) port 8000
* Server auth using Basic with user 'admin'
> GET /metrics HTTP/1.1
> Host: localhost:8000
> Authorization: Basic YWRtaW46c2VjcmV0
> User-Agent: curl/8.6.0
> Accept: */*
>
< HTTP/1.1 200 OK
< Content-Type: text/plain; version=0.0.4; charset=utf-8; escaping=values
< X-Request-Id: twBumHzpwjeQQrAJJffEcZdWbCDmmJRC
< Date: Fri, 21 Jun 2024 13:09:55 GMT
< Transfer-Encoding: chunked

$ curl http://localhost:8000/_heath -v
* Host localhost:8000 was resolved.
* IPv6: ::1
* IPv4: 127.0.0.1
*   Trying [::1]:8000...
* Connected to localhost (::1) port 8000
> GET /_heath HTTP/1.1
> Host: localhost:8000
> User-Agent: curl/8.6.0
> Accept: */*
>
< HTTP/1.1 200 OK
< Content-Type: application/json
< X-Request-Id: mbWzmzsFxWAyfYIPVmThqHIsdGxCHmTt
< Date: Fri, 21 Jun 2024 13:09:33 GMT
< Content-Length: 0

Finally In prometheus, you can set the Authorization header on every scrape request with the configured username and password. Check the scrape_configs configuration

scrape_configs:
  - job_name: my_app
    basic_auth:
        username: admin!
        password: secret!
    static_configs:
        - targets:
            - 'localhost:8000'
