Kubernetes Deployment in a Nutshell

04 April 2020

Deployment is a higher-level resource meant for deploying applications and updating them declaratively, instead of doing it through a ReplicationController or a ReplicaSet, which are both considered lower-level concepts.

Creating a Deployment

A Deployment is also composed of a label selector, a desired replica count, and a pod template. In addition to that, it also contains a field, which specifies a deployment strategy that defines how an update should be performed when the Deployment resource is modified.

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: toad-deployment
spec:
  replicas: 4
  selector:
    matchLabels:
      app: toad
  template:
    metadata:
      labels:
        app: toad
      name: toad
    spec:
      containers:
        -
          image: "clivern/toad:release-0.2.2"
          name: toad-app

You’re now ready to create the Deployment:

$ kubectl create -f toad-deployment-v0.2.2.yaml --record

deployment "toad-deployment" created

Be sure to include the --record command-line option when creating it. This records the command in the revision history

Checking a Deployment’s status:

$ kubectl rollout status deployment toad-deployment

Waiting for deployment "toad-deployment" rollout to finish: 0 of 4 updated replicas are available...
Waiting for deployment "toad-deployment" rollout to finish: 1 of 4 updated replicas are available...
Waiting for deployment "toad-deployment" rollout to finish: 2 of 4 updated replicas are available...
Waiting for deployment "toad-deployment" rollout to finish: 3 of 4 updated replicas are available...
deployment "toad-deployment" successfully rolled out

You should see the four pod replicas up and running:

$ kubectl get pods

The four pods created by the Deployment include an additional numeric value in the middle of their names. The number corresponds to the hashed value of the pod template in the Deployment and the ReplicaSet managing these pods.

a Deployment doesn’t manage pods directly. Instead, it creates ReplicaSets and leaves the managing to them, so let’s look at the ReplicaSet created by your Deployment:

$ kubectl get replicasets

NAME                        DESIRED   CURRENT   AGE
toad-deployment-cc56589c4   4         4         10s

Updating a Deployment

Kubernetes will take all the steps necessary to get the actual system state to what’s defined in the resource. Similar to scaling a ReplicationController or ReplicaSet up or down, all you need to do is reference a new image tag in the Deployment’s pod template and leave it to Kubernetes to transform your system so it matches the new desired state.

The Recreate strategy causes all old pods to be deleted before the new ones are created. Use this strategy when your application doesn’t support running multiple versions in parallel and requires the old version to be stopped completely before the new one is started. This strategy does involve a short period of time when your app becomes completely unavailable.

The RollingUpdate strategy, on the other hand, removes old pods one by one, while adding new ones at the same time, keeping the application available throughout the whole process, and ensuring there’s no drop in its capacity to handle requests. This is the default strategy. The upper and lower limits for the number of pods above or below the desired replica count are configurable. You should use this strategy only when your app can handle running both the old and new version at the same time.

When you execute this command, you’re updating the toad Deployment’s pod template so the image used in its toad-app container is changed to clivern/toad:release-0.2.3

$ kubectl set image deployment toad-deployment toad-app=clivern/toad:release-0.2.3 --record

deployment "toad-deployment" image updated

You can follow the progress of the rollout with kubectl rollout status:

$ kubectl rollout status deployment toad-deployment

To undo the last rollout of a Deployment:

$ kubectl rollout undo deployment toad-deployment

deployment "toad-deployment" rolled back

This rolls the Deployment back to the previous revision.

The revision history can be displayed with the kubectl rollout history command:

$ kubectl rollout history deployment toad-deployment

deployments "toad-deployment":
REVISION    CHANGE-CAUSE
2           kubectl set image deployment toad-deployment toad_app=clivern/toad:release-0.2.2
3           kubectl set image deployment toad-deployment toad_app=clivern/toad:release-0.2.3

You can roll back to a specific revision by specifying the revision in the undo command.

$ kubectl rollout undo deployment toad-deployment --to-revision=1

Controlling the rate of the rollout

Two properties affect how many pods are replaced at once during a Deployment’s rolling update. They are maxSurge and maxUnavailable and can be set as part of the rollingUpdate sub-property of the Deployment’s strategy attribute, as shown in the following listing.

spec:
    strategy:
        rollingUpdate:
            maxSurge: 1
            maxUnavailable: 0
        type: RollingUpdate

maxSurge: Determines how many pod instances you allow to exist above the desired replica count configured on the deployment. It defaults to 25%, so there can be at most 25% more pod instances than the desired count. If the desired replica count is set to four, there will never be more than five pod instances running at the same time during an update. When converting a percentage to an absolute number, the number is rounded up. Instead of a percentage, the value can also be an absolute value (for example, one or two additional pods can be allowed).

maxUnavailable: Determines how many pod instances can be unavailable relative to the desired replica count during the update. It also defaults to 25%, so the number of available pod instances must never fall below 75% of the desired replica count. Here, when converting a percentage to an absolute number, the number is rounded down. If the desired replica count is set to four and the percentage is 25%, only one pod can be unavailable. There will always be at least three pod instances available to serve requests during the whole rollout. As with maxSurge, you can also specify an absolute value instead of a percentage.

You can trigger the rollout by changing the image to clivern/toad:release-0.2.4, but then immediately (within a few seconds) pause the rollout (canary release).

A canary release is a technique for minimizing the risk of rolling out a bad version of an application and it affecting all your users. Instead of rolling out the new version to everyone, you replace only one or a small number of old pods with new ones.

$ kubectl set image deployment toad-deployment toad-app=clivern/toad:release-0.2.3
deployment "toad-deployment" image updated

$ kubectl rollout pause deployment toad-deployment
deployment "toad-deployment" paused

Once you’re confident the new version works as it should, you can resume the deployment to replace all the old pods with new ones:

$ kubectl rollout resume deployment toad-deployment
deployment "toad-deployment" resumed

Blocking rollouts of bad versions

The minReadySeconds property specifies how long a newly created pod should be ready before the pod is treated as available. Until the pod is available, the rollout process will not continue (remember the maxUnavailable property?). A pod is ready when readiness probes of all its containers return a success. If a new pod isn’t functioning properly and its readiness probe starts failing before minReadySeconds have passed, the rollout of the new version will effectively be blocked.

The fact that the deployment will stuck is a good thing, because if it had continued replacing the old pods with the new ones, you’d end up with a completely non-working service

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: toad-deployment
spec:
  minReadySeconds: 10
  replicas: 4
  selector:
    matchLabels:
      app: toad
  strategy:
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0
    type: RollingUpdate
  template:
    metadata:
      labels:
        app: toad
      name: toad
    spec:
      containers:
        -
          image: "clivern/toad:release-0.2.3"
          name: toad-app
          readinessProbe:
            httpGet:
              path: /_ready
              port: 8080
            initialDelaySeconds: 5
            periodSeconds: 10
          livenessProbe:
            httpGet:
              path: /_health
              port: 8080
            initialDelaySeconds: 10
            periodSeconds: 5

Usually, you’d set minReadySeconds to something much higher to make sure pods keep reporting they’re ready after they’ve already started receiving actual traffic.

If you’re interested in practising, giving some help! you should check this repository https://github.com/Clivern/Toad or this one https://github.com/Clivern/Beetle
